视觉UV打印机1200*600mm




所属分类:

UV打印机

图片名称

详情介绍

设备参数

Equipment parameters:

设备类型

Equipment Type

线扫视觉UV打印机(UV printer with line scan CCD

设备型号

Equipment Model

UV-0906

UV-1208

UV-1810

工作台尺寸(mm)

Work Table Size

900x600

1200 x800

1800x1000

工作范围(mm)

Scope of work

900x600

1200 x800

1800x1000

相机

Camera

4K 线扫相机

镜头

Lens

远心镜头

80mm口径

远心镜头

120mm口径

远心镜头

150mm口径

机器尺寸

Machine Size

2050mmx1600mmx1550mm

2500mmx1550mmx1580mm

3100mmx1800mmx1650mm

机器重量

Machine Total Weight

950kg

1100kg

1300kg



电脑主机参数

PC parameters:

CPU

AMD Ryzen 7 5700G   816线程

内存

Memory

64G

硬盘

Hard disk

1TB固态硬盘

显示器

Monitor

1920*1080分辨率,大小27英寸



打印头理光 G5i/G6 、爱普生I3200

颜色配置G5i4色(4头)或者8色(5头);G66色(6头);

I32008色(5头)或者9色(6头)

墨水 环保UV油墨

固化方式 UV-LED 冷光源

打印分辨率 1200DPI, 1800DPI, 2400DPI

计算机系统 Win7/win10

传输接口 USB-2.0/3.0

平台大理石高度平台

功率2.5KW

电源 AC220V/50Hz/10A

辅助功能:视觉定位、自动防撞

环境要求: 最佳温度为26-30℃,相对湿度为40-60%

清洁、无尘、无阳光直射、通风良好的环境

涉及行业:

徽章奖牌、玩具行业,化妆品行业、工艺品行业,鞋材行业、手机壳行业、标识标牌行业、金属行业、皮革布艺、文具行业。

特征和优点:

•标准四色,白色通道、光油通道、涂层通道和四个浅色通道可选,颜色逼真

•涂层通道提高油墨附着力,打印效果持久耐刮

4K线扫相机拍照精度高,适合高精度徽章工艺品拍照

•可调UV固化LED

•灰度可变

•软件可选Photoprintsever.Maintop.Riprint

•两层专色打印功能,支持打印CWC模式和WCV模式

介质/处理:

板介质类型:铜材/铝板/陶瓷/亚克PVC

•打印图片格式:所有常用格式,包括TIFFJPEG

•颜色空间:RGBCMYK



环境要求:

•温度:20-28 摄氏度

•湿度:40-60% (无冷凝)

•用电要求: 220V 50hz 2500W

  • Print Heads: Ricoh G5i/G6, Epson I3200
  • Color Configuration: G5i: 4 colors (4 print heads) or 8 colors (5 print heads); G6: 6 colors (6 print heads); I3200: 8 colors (5 print heads) or 9 colors (6 print heads)"
  • Ink: Eco-friendly UV ink
  • Curing Method: UV-LED water-cooled light source
  • Printing Resolution: 1200DPI, 1800DPI, 2400DPI
  • Computer System: Windows 7/Windows 10
  • Transmission Interface: USB 2.0/3.0
  • Platform: High-precision marble platform
  • Power: 2.5KW
  • Power Supply: AC220V/50Hz/10A
  • Auxiliary Features: Visual positioning, automatic collision prevention
  • Environmental Requirements: Ideal temperature 20-28°C, relative humidity 40-60%, clean, dust-free, no direct sunlight, well-ventilated environment

Industries involved:

  • Badge and medal industry, toy industry, cosmetics industry, handicraft industry, footwear industry, mobile phone case industry, signage and nameplate industry, metal industry, leather and fabric, stationery industry.





Features and Advantages:

  • Standard four colors, optional white channel, light oil channel, coating channel, and four light color channels for realistic colors.
  • The coating channel improves ink adhesion, ensuring long-lasting and scratch-resistant printing effects.
  • 4K line scan camera for high-precision imaging, suitable for high-precision badge and handicraft photography.
  • Adjustable UV curing LED lamp.
  • Variable grayscale.
  • Software options include Photoprint Server, Maintop, or Riprint.
  • Two-layer spot color printing function, supporting CWC mode and WCV mode.

Media/Processing:

  • Board substrate types: Copper, aluminum, ceramics, PVC, etc.
  • Supported image formats: All common formats, including TIFF, JPEG, etc.
  • Color spaces: RGB and CMYK

Environmental Requirements:

  • Temperature: 20-28 degrees Celsius.
  • Humidity: 40-60% (non-condensing).
  • Electrical Requirements: 220V 50Hz 2500W.
